  • Product outline

    Kordz ONE Series CAT6 U/UTP cable is engineered to exceed 4K video installation bandwidth requirements. The Rapid-EZ reel is metre marked and flows from the supplied professional pull box without twisting or curling, minimising snags for optimal installation uptime. ONE series CAT6 cable is tested and approved to exceed 550Mhz, is HDBaseT™ recommended and exceeds ANSI/TIA 568C-2.1 Standard.

    • Suitable for 10BASE-T, 100BASE-TX, 1000BASE-T/1000BASE-TX (Gigabit) & 5GBaseT, PoE & PoE+
    • U/UTP Ethernet CAT6
    • Four Twisted Pairs 24 AWG Oxygen Free Solid Copper Conductors
    • PVC Separator Reduces Crosstalk Between Pairs
    • Suitable for IDC Terminations
    • Supplied in the Durable Rapid-EZ-Reel Packaging – 305m (1,000ft)
    • Metre Marked for installation accuracy
    • 5 Colours Available: Blue, Green, White, Yellow & Purple
    • Exceeds ANSI/TIA 568C-2.1 Standard
    • Available In LSZH – IEC60332-1 And UL 444 CM fire rated versions
    • CPR Declared Performance: ONE-CAT6: Dca-s2, d2, a1 (EN 50575:2014+A1:2016)
  • Technical info

    CONSTRUCTION

    Conductor: Solid OFC annealed bare copper wire 0.537 +0/-0.015mm [24AWG]
    Insulation: Polyethylene, 0.97 +/-0.05 mm
    Twisting: 4 twisted pairs, 2 cores to each pair
    Twisted Pair Colour Code: 1 – white-blue/blue, 2 – white-orange/orange, 3 – white-green/green, 4 – white-brown/brown
    Cable Lay-Up: 4 pairs with different pitches, non-metallic cross separator (spine)
    Outer Diameter: 5.7 +/-0.3 mm

    MECHANICAL

    Bend Radius: without load ≥ 22.8mm /0.89”, with load ≥ 45.6mm /1.79”
    Temperature Range: During Operation: -20°C to 60ºC During Installation:  0°C to 50ºC

    ELECTRICAL

    DC Resistance: ≤ 9.38Ω / 100m at 20ºC
    Resistance Unbalance: ≤ 5% at 20ºC
    Insulation Resistance (500V): ≥ 5000MΩ / km at 20ºC
    Mutual Capacitance: ≤ 5.6 nF / 100m at 1kHz
    Capacitance Unbalance (Pair to Ground): ≤ 330 pF / 100m at 1kHz
    Nominal Velocity of Propagation: nom. 67% c
    Test Voltage: 1kV DC / 1 min



    MATERIALS/MARKING & FIRE RATING

    LSZH
    Kordz ONE Solid OFC UHD/4K Video/Data Network Cable. ETL VERIFIED TIA-568-C.2 (3081133CRT-009) LSZH CAT6 U/UTP 24AWG. IEC 60332-1

    FRPVC
    Kordz ONE Solid OFC UHD/4K Video/Data Network Cable. ETL VERIFIED TIA-568-C.2 (2042398CRT-004) CM CAT6 U/UTP 24AWG. UL 444 CM

    Blue: RAL 5015
    Green: RAL 6018
    Purple: RAL 4005
    White: RAL 9003
    Yellow: RAL 1018



    PACKAGING

    Roll Size: 305m / 1000ft – metre marked
    Carton Dimensions: 330mm (W) x 265mm (D) x 340mm (H) / 13.0in (W) x 10.4in (D) x 13.4in (H)
    Volume: 0.03m2 / 1.05 cu. ft.
    Gross Weight: 13.8kg / 30.4lbs

  • Downloads

ONE Series CAT 6 U/UTP – 305m Pro Box

Kordz ONE Series CAT6 U/UTP cable exceeds 4K video installation bandwidth requirements and flows from the supplied professional pull box without twisting or curling, minimising snags for optimal installation uptime.

Colour options:

  • Product Code
  • Description
  • K13002-305M-BL 305m
  • K13005-305M-BL 305m
  • K13002-305M-GN 305m
  • K13002-305M-PP 305m
  • K13005-305M-PP 305m
  • K13002-305M-WH 305m
  • K13005-305M-WH 305m
  • K13002-305M-YL 305m
