Technology

  • Product outline



    • Suitable for 10BASE-T, 100BASE-TX, 1000BASE-T/1000BASE-TX (Gigabit) & 10GBaseT, PoE & PoE+
    • F/UTP Ethernet CAT6a
    • Four Twisted Pairs 23 AWG Solid Copper Conductors
    • PVC Separator Reduces Crosstalk Between Pairs
    • Mylar laminated aluminium tape shielding with a 26AWG drain wire
    • Suitable for IDC Terminations
    • Supplied in the durable Rapid-EZ-Reel packaging – 152.5m (500ft)
    • Metre Marked
    • 5 colours available: Blue, Green, White, Yellow & Purple
    • Exceeds ANSI/TIA 568-C.2 and ISO/IEC 61156-5 standards
    • Available in LSZH – IEC60332-3-25 and UL 444 CM fire rated versions
    • CPR Declared Performance: ONE-CAT6A: Dca-s1, d2, a1 (EN 50575:2014+A1:2016)
  • Technical info

    CONSTRUCTION

    Conductor: Solid OFC annealed bare copper wire 0.561 +0/-0.015mm [23AWG]
    Insulation: Orange & Brown Pairs – Polyethylene (PE), 1.12+/-0.05 mm Blue & Green Pairs – Foam PE, 0.97 +/-0.05 mm
    Twisting: 4 twisted pairs, 2 cores to each pair
    Twisted Pair Colour Code: 1 – white-blue/blue, 2 – white-orange/orange, 3 – white-green/green, 4 – white-brown/brown
    Cable Lay-Up: 4 pairs with different pitches, non-metallic cross separator (spine)
    Shielding: Drain wire [26AWG], Mylar tape laminated with aluminium foil as a shield
    Outer Diameter: 7.4 +/-0.3 mm

    MECHANICAL

    Bend Radius: without load ≥ 29.6mm /1.16”, with load ≥ 59.2mm /2.33”
    Temperature Range: During Operation: -20°C to 60ºC During Installation: 0°C to 50ºC

    ELECTRICAL

    DC Resistance: ≤ 9.38Ω / 100m at 20ºC
    Resistance Unbalance: ≤ 2% at 20ºC
    Insulation Resistance (500V): ≥ 5000MΩ / km at 20ºC
    Mutual Capacitance: ≤ 5.1 nf / 100m at 1khz
    Capacitance Unbalance (pair to ground): ≤ 160 pf / 100m at 1khz
    Nominal Velocity of Propagation: nom. 67% c
    Test Voltage: 1kV DC / 1 min



    MATERIALS/MARKING & FIRE RATINGS

    LSZH
    Kordz ONE Solid OFC UHD/4K Video Network Cable. ETL VERIFIED TIA-568-C.2 (100372289CRT-001c) LSZH CAT6A F/UTP 23AWG. IEC 60332-3-25

    FRPVC
    Kordz ONE Solid OFC UHD/4K Video Network Cable. ETL VERIFIED TIA-568-C.2 (100709714CRT-002c) CM CAT6A F/UTP 23AWG. UL 444 CM

    Blue: RAL 5015
    Green: RAL 6018
    Purple: RAL 4005
    White: RAL 9003
    Yellow: RAL 1018



    PACKAGING

    Roll Size: 152.5m / 500ft – metre marked
    Carton Dimensions: 330mm (W) x 265mm (D) x 340mm (H) / 13.0in (W) x 10.4in (D) x 13.4in (H)
    Volume: 0.03m2 / 1.05 cu. ft.
    Gross Weight: 9.8kg / 21.6lbs

  • Downloads

ONE Series CAT 6A F/UTP – 152m Pro Box

Kordz ONE Series CAT 6A F/UTP premium cable is engineered to exceed 4K video installation bandwidth requirements and minimise alien crosstalk or electromagnetic interference in complex systems. The Rapid-EZ reel is metre marked and flows from the supplied professional pull box without twisting or curling, minimising snags for optimal installation uptime. ONE series CAT 6A F/UTP cable is tested and approved to exceed 550Mhz, ANSI/TIA 568-C.2 and ISO/IEC 61156-5 standards.

Black Colour Released now. Stock available in Q3 2022. Contact your nearest distributor to pre order.

Colour options:

  • Product Code
  • Description
  • K13605-152M-BK

    152m / 500ft, Black / CM

  • K13602-152M-BK

    152m / 500ft, Black / LSZH

  • K13602-152M-BL

    152m / 500ft, Blue / LSZH

  • K13605-152M-BL

    152m / 500ft, Blue / CM

  • K13602-152M-GN

    152m / 500ft, Green / LSZH

  • K13605-152M-GN

    152m / 500ft, Green / CM

  • K13602-152M-PP

    152m / 500ft, Purple / LSZH

  • K13605-152M-PP

    152m / 500ft, Purple / CM

  • K13602-152M-WH

    152m / 500ft, White / LSZH

  • K13605-152M-WH

    152m / 500ft, White / CM

  • K13602-152M-YL

    152m / 500ft, Yellow / LSZH

  • K13605-152M-YL

    152m / 500ft, Yellow
